KNX BASIC COURSE

Table of Contents

1 Diagnostics and fault location ...................................................................................... 3
2 Diagnostics: Individual addresses................................................................................ 4
2.1 Devices in Programming Mode ............................................................................ 4
2.2 Checking if an address exists and locating the device ........................................ 5
2.3 Listing all existing addresses in a line .................................................................. 5
3 Diagnostics: Device Info, reading out devices ............................................................. 8
4 Diagnostics: Bus monitoring and Group monitoring ................................................... 10

4.1 Starting and stopping a telegram recording ....................................................... 11
4.2 Bus Monitoring...................................................................................................11
4.3 Group monitoring ...............................................................................................12
4.4 Properties of individual telegrams ...................................................................... 14
4.5 Options for telegram recording .......................................................................... 16
4.5.1 General .......................................................................................................... 16
4.5.2 Recording ....................................................................................................... 17
4.5.3 Colouring ........................................................................................................ 18
4.5.4 Conditions ...................................................................................................... 19
4.6 Saving telegrams ...............................................................................................19
4.7 Opening telegrams from file ............................................................................... 20
4.8 Clearing the telegram list ................................................................................... 20
4.9 Replaying telegrams ..........................................................................................22
5 Group addresses: Read value ................................................................................... 23
6 Group addresses: Write value ................................................................................... 24
7 Diagnostics: Project Check ........................................................................................ 25
7.1 Device Check.....................................................................................................26
7.2 Group Address Check ........................................................................................ 26
7.3 Topology Check .................................................................................................27
7.4 Product Information Check ................................................................................ 27
8 Diagnostics: Online Error Diagnostics ....................................................................... 28
9 Diagnostics: Online Installation Diagnostics Wizard .................................................. 32
10 Diagnostics: Tool Diagnostics .................................................................................... 34

Home and Building Management Systems KNX Association
ETS Diagnostics ETS4_Diagnostics_E0111c 2/37
