DOUBLE-END CLAMP STRAPS

A clamp-strap assembly with two
clamping ends, for holding two
workpieces simultaneously. Choose from
three different fastening devices, each
available in a short or tall version, and two
clamp-strap lengths. Order components
individually.
SPHERICAL NUT & WASHER (SHORT)
CLAMPING- CLAMP STRAP CLAMP FLAT JAM SPHERICAL NUT
HEIGHT (INFO++: p. 270) SPRINGS WASHER NUT STUD & WASHER
SIZE RANGE PART NO. LENGTH A (p. 320) (p. 307) (p. 304) (p. 310) (p. 306)
CL-23C-CS 2 27/32
MINI 0 to 1-1/16 CL-6-SPG CL-14-FW CL-5-JN CL-5/16-18x3.00 CL-9-SNW
Spherical CL-23D-CS 3 1-11/32
Nut & Washer STANDARD 0 to 1-3/8 CL-28-CS 5 2-19/64 CL-9-SPG CL-2-FW CL-8-JN CL-1/2-13x4.00 CL-3-SNW
CL-30-CS 6 2-51/64
CL-32A-CS 5 2-1/4
A A HEAVY 0 to 1-3/8 CL-33-CS 6 2-3/4 CL-11-SPG CL-3-FW CL-10-JN CL-5/8-11x4.50 CL-4-SNW
SPHERICAL NUT & WASHER (TALL)
Mini CL-23C-CS 2 27/32
MINI 1 to 1-3/4 (2) CL-6-SPG CL-14-FW CL-5-JN CL-5/16-18x3.50 CL-9-SNW
Standard CL-23D-CS 3 1-11/32
Heavy CL-28-CS 5 2-19/64
STANDARD 1-3/8 to 2-3/4 (2) CL-9-SPG CL-2-FW CL-8-JN CL-1/2-13x5.50 CL-3-SNW
CL-30-CS 6 2-51/64
CL-32A-CS 5 2-1/4
HEAVY 1-3/8 to 2-1/2 (2)CL-11-SPG CL-3-FW CL-10-JN CL-5/8-11x5.50 CL-4-SNW
CL-33-CS 6 2-3/4
HAND KNOB (SHORT)
CLAMPING- CLAMP STRAP CLAMP FLAT JAM HAND SPHERICAL NUT
HEIGHT (INFO++: p. 270) SPRINGS WASHER NUT STUD KNOB & WASHER
SIZE RANGE PART NO. LENGTH A (p. 320) (p. 307) (p. 304) (p. 310) (p. 100) (p. 306)
CL-23C-CS 2 27/32
MINI 0 to 1-1/16 CL-6-SPG CL-14-FW CL-5-JN CL-5/16-18x3.00 CL-2-HK-2 CL-11-SW
Hand CL-23D-CS 3 5 1-11/32
2-19/64
CL-28-CS
Knob STANDARD 0 to 1-3/8 CL-9-SPG CL-2-FW CL-8-JN CL-1/2-13x4.00 CL-4-HK-4 CL-3-SW
CL-30-CS 6 2-51/64
CL-32A-CS 5 2-1/4
HEAVY 0 to 1-3/8 CL-11-SPG CL-3-FW CL-10-JN CL-5/8-11x4.50 CL-10-HK-10 CL-4-SW
A A CL-33-CS 6 2-3/4
HAND KNOB (TALL)
Mini MINI 1 to 1-3/4 CL-23C-CS 2 27/32 (2) CL-6-SPG CL-14-FW CL-5-JN CL-5/16-18x3.50 CL-2-HK-2 CL-11-SW
Standard CL-23D-CS 3 1-11/32
CL-28-CS 5 2-19/64
Heavy STANDARD 1-3/8 to 2-3/4 (2) CL-9-SPG CL-2-FW CL-8-JN CL-1/2-13x5.50 CL-4-HK-4 CL-3-SW 10
CL-30-CS 6 2-51/64
CL-32A-CS 5 2-1/4
HEAVY 1-3/8 to 2-1/2 (2)CL-11-SPG CL-3-FW CL-10-JN CL-5/8-11x5.50 CL-10-HK-10 CL-4-SW
CL-33-CS 6 2-3/4
CAM HANDLE (SHORT)
CLAMPING- CLAMP STRAP CLAMP FLAT JAM SPHERICAL NUT CAM EYE DOWEL
HEIGHT (INFO++: p. 270) SPRINGS WASHER NUT & WASHER HANDLE BOLT PIN
SIZE RANGE PART NO. LENGTH A (p. 320) (p. 307) (p. 304) (p. 306) (p. 318) (p. 316) (p. 240)
Cam MINI 0 to 1-1/16 CL-23C-CS 2 27/32 CL-6-SPG CL-14-FW CL-5-JN CL-11-SW CL-11A-CH CL-31-EB CL-1/4x.62-CADP
Handle CL-23D-CS 3 1-11/32
CL-28-CS 5 2-19/64
STANDARD 0 to 1-3/8 CL-9-SPG CL-2-FW CL-8-JN CL-3-SW CL-13-CH CL-50-EB CL-3/8x1.00-CADP
CL-30-CS 6 2-51/64
A A CL-32A-CS 5 2-1/4
HEAVY 0 to 1-3/8 CL-11-SPG CL-3-FW CL-10-JN CL-4-SW CL-14-CH CL-62-EB CL-5/8x1.25-CADP
CL-33-CS 6 2-3/4
SPHERICAL NUT & WASHER (TALL)
Mini CL-23C-CS 2 27/32
Standard MINI 1 to 1-3/4 CL-23D-CS 3 1-11/32 (2) CL-6-SPG CL-14-FW CL-5-JN CL-11-SW CL-11A-CH CL-32-EB CL-1/4x.62-CADP
Heavy CL-28-CS 5 2-19/64
STANDARD 1-3/8 to 2-3/4 (2) CL-9-SPG CL-2-FW CL-8-JN CL-3-SW CL-13-CH CL-51-EB CL-3/8x1.00-CADP
CL-30-CS 6 2-51/64
CL-32A-CS 5 2-1/4
HEAVY 1-3/8 to 2-1/2 (2)CL-11-SPG CL-3-FW CL-10-JN CL-4-SW CL-14-CH CL-63-EB CL-5/8x1.25-CADP
CL-33-CS 6 2-3/4
