Why Carr Lane Roemheld Swing Clamps?

Designed for 1,000,000 cycles

2,000,000+ cycles tested at full load

• Rod diameter 30% larger to eliminate part deflection
• Viton wiper is standard (metal wiper optional)

• Exclusive safety clutch design available to prevent damage to part, fixture, or operator
• Reinforced swivel mechanism with 2 or 3 helix paths depending on size for longer life
• Up to 7500 psi maximum pressure for more compact clamp design

• Position monitoring available, either inductive or pneumatic via movable sensing bolt
• Over 1000 different standard sizes and styles available with clamping forces from 130
lb. to 8265 lb. stroke up to 2”
• Special stroke and clamping forces available upon request.

See Page 640-650

Versatile Modular Units For Assembly and Handling

• Combine our modular units
to Lift, Tilt, Rotate or Move
your assembly

• Easily move your assembly
to optimal position to
increase productivity and
reduce fatigue

• Preset positions for long
runs or adjustable locations
for flexibility
14

See Pages 742-743
