END MILLS
3835 AlumaMill - Square End
Long Reach
3 Flutes
36˚ High Helix
Right Hand Spiral
Right Hand Cut
Dura Carb (Micrograin)
Speeds and Feeds, see fullertontool.com
Tolerance:
Shank Diameter: h6
Cutter Diameter: +.0000” -.0005”
+0.000mm -0.013mm
Tool Cutting Shank Overall Neck EDP Number
Cutting Diameter Length Length Diameter Length Reach Diameter Advanced
Style UC FC 19 Performance
Metric
6.00 LR 20.00 6.00 100.00 50.00 5.75 92487 92548
8.00 LR 20.00 8.00 100.00 50.00 7.70 92488 92549
10.00 LR 25.00 10.00 100.00 57.00 9.60 92489 92550
12.00 LR 25.00 12.00 100.00 57.00 11.60 92490 92551
16.00 LR 30.00 16.00 150.00 89.00 15.34 92491 92552
20.00 LR 38.00 20.00 150.00 89.00 19.35 92492 92553
25.00 LR 38.00 25.00 150.00 89.00 24.00 92493 92554
UNCOATED
FC-19
M
METRIC
■ Brass & Copper ■ High Si Al ■ Low Si Al ■ Composites ■ Plastics ■ General Purpose
