Page 627 - Deko-Light Light Impressions 2019-20
P. 627
ULTRA-FLEXIBLE LED-STRIPE
Dim. L x W x H: 3000 x 5 x 3 mm
LED rows: 1
Fixation: Adhesive tape rear side
Stripe connection: 2 cables [V-, V+]
840041 3000 K [+/- 150 K] 225 LEDs 25 W 780 lm / Stripe 260 lm / Meter EEI: A
840042 6000 K [+/- 150 K] 225 LEDs 25 W 900 lm / Stripe 300 lm / Meter EEI: A
24 SMD 120° 1 CH IP20 - 15°C M M
3528 + 50°C
Cutting option
over to 40 mm / 3 LED
FLEXIBLE LED-STRIPE
Dim. L x W x H: 3000 x 5 x 3 mm
LED rows: 1
Fixation: Adhesive tape rear side
Stripe connection: 2 cables [V-, V+]
840155 3000 K [+/- 150 K] 360 LEDs 30 W 2000 lm / Stripe 666 lm / Meter EEI: A
840154 2700 K [+/- 150 K] 360 LEDs 30 W 1900 lm / Stripe 633 lm / Meter EEI: A
840156 4000 K [+/- 150 K] 360 LEDs 30 W 2000 lm / Stripe 666 lm / Meter EEI: A
840157 6200 K [+/- 150 K] 360 LEDs 30 W 2000 lm / Stripe 666 lm / Meter EEI: A
24 SMD 120° Ra>90 1 CH IP20 - 15°C M M
3528 + 50°C
Cutting option
over to 50 mm / 6 LED
626 LED-STRIPES | 1 Channel
