Page 629 - Deko-Light Light Impressions 2019-20
P. 629
FLEXIBLE LED-STRIPE
Dim. L x W x H: 3000 x 8 x 3 mm
LED rows: 1
Fixation: Adhesive tape rear side
Stripe connection: 2 cables [V-, V+]
840162 2700 K [+/- 150 K] 360 LEDs 25 W 1700 lm / Stripe 566 lm / Meter EEI: A
840035 3000 K [+/- 150 K] 360 LEDs 25 W 1700 lm / Stripe 566 lm / Meter EEI: A
840163 4000 K [+/- 150 K] 360 LEDs 25 W 1800 lm / Stripe 600 lm / Meter EEI: A
840036 6500 K [+/- 150 K] 360 LEDs 25 W 1800 lm / Stripe 600 lm / Meter EEI: A
24 SMD 120° 1 CH IP20 - 15°C M M
3528 + 50°C
Cutting option
over to 25 mm / 3 LED
FLEXIBLE LED-STRIPE
Dim. L x W x H: 5000 x 8 x 3 mm
LED rows: 1
Fixation: Adhesive tape rear side
Stripe connection: 2 cables [V-, V+]
840164 2700 K [+/- 150 K] 600 LEDs 30 W 2250 lm / Stripe 450 lm / Meter EEI: A
840165 3000 K [+/- 150 K] 600 LEDs 30 W 2300 lm / Stripe 460 lm / Meter EEI: A
840166 4000 K [+/- 150 K] 600 LEDs 30 W 2400 lm / Stripe 480 lm / Meter EEI: A
840167 6500 K [+/- 150 K] 600 LEDs 30 W 2400 lm / Stripe 480 lm / Meter EEI: A
24 SMD 120° 1 CH IP20 - 15°C M M
3528 + 50°C
Cutting option
over to 25 mm / 3 LED
628 LED-STRIPES | 1 Channel
