Page 631 - Deko-Light Light Impressions 2019-20
P. 631
FLEXIBLE LED-STRIPE
Dim. L x W x H: 3000 x 10 x 2 mm
LED rows: 1
Fixation: Adhesive tape rear side
Stripe connection: 2 cables [V-, V+]
840196 2700 K [+/- 150 K] 180 LEDs 38 W 2300 lm / Stripe 766 lm / Meter EEI: A
840197 3000 K [+/- 150 K] 180 LEDs 38 W 2300 lm / Stripe 766 lm / Meter EEI: A
840198 4000 K [+/- 150 K] 180 LEDs 38 W 2400 lm / Stripe 800 lm / Meter EEI: A
840199 6500 K [+/- 150 K] 180 LEDs 38 W 2400 lm / Stripe 800 lm / Meter EEI: A
12 SMD 120° Ra>90 1 CH IP20 - 15°C M M
2835 + 50°C
Cutting option
over to 50 mm / 3 LED
FLEXIBLE LED-STRIPE
Dim. L x W x H: 5000 x 10 x 2 mm
LED rows: 1
Fixation: Adhesive tape rear side
Stripe connection: 2 cables [V-, V+]
840200 2700 K [+/- 150 K] 300 LEDs 40 W 3000 lm / Stripe 600 lm / Meter EEI: A
840117 3000 K [+/- 150 K] 300 LEDs 40 W 3300 lm / Stripe 660 lm / Meter EEI: A
840118 4000 K [+/- 150 K] 300 LEDs 40 W 3300 lm / Stripe 660 lm / Meter EEI: A
840119 6000 K [+/- 150 K] 300 LEDs 40 W 3300 lm / Stripe 660 lm / Meter EEI: A
12 SMD 120° Ra>90 1 CH IP20 - 15°C M M
2835 + 50°C
Cutting option
over to 50 mm / 3 LED
630 LED-STRIPES | 1 Channel
