Page 639 - Deko-Light Light Impressions 2019-20
P. 639
FLEXIBLE LED-STRIPE
Dim. L x W x H: 3000 x 10 x 3 mm
LED rows: 1
Fixation: Adhesive tape rear side
Stripe connection: 2 cables [V-, V+]
840258 2700 K [+/- 150 K] 216 LEDs 38 W 2450 lm / Stripe 816 lm / Meter EEI: A
840246 3000 K [+/- 150 K] 216 LEDs 38 W 2500 lm / Stripe 833 lm / Meter EEI: A
840259 4000 K [+/- 150 K] 216 LEDs 38 W 2600 lm / Stripe 866 lm / Meter EEI: A
840260 6000 K [+/- 150 K] 216 LEDs 38 W 2600 lm / Stripe 866 lm / Meter EEI: A
12 SMD - 15°C M M
5050 120° Ra>90 1 CH IP33 + 50°C
Cutting option
over to 14 mm / 1 LED
FLEXIBLE LED-STRIPE
Dim. L x W x H: 5000 x 8 x 3 mm
LED rows: 1
Fixation: Adhesive tape rear side
Stripe connection: 2 cables [V-, V+]
NANO Coating [Lotus effect]
Water rolls off and takes all dirty surface particles with it.
840168 2700 K [+/- 150 K] 600 LEDs 30 W 2200 lm / Stripe 440 lm / Meter EEI: A
840169 3000 K [+/- 150 K] 600 LEDs 30 W 2300 lm / Stripe 460 lm / Meter EEI: A
840170 4000 K [+/- 150 K] 600 LEDs 30 W 2400 lm / Stripe 480 lm / Meter EEI: A
840171 6500 K [+/- 150 K] 600 LEDs 30 W 2400 lm / Stripe 480 lm / Meter EEI: A
12 SMD 120° Ra>90 1 CH IP44 - 15°C M M
3528 + 50°C
Cutting option
over to 25 mm / 3 LED
638 LED-STRIPES | 1 Channel
