Page 634 - Deko-Light Light Impressions 2019-20
P. 634
FLEXIBLE LED-STRIPE
Dim. L x W x H: 3000 x 10 x 3 mm
LED rows: 1
Fixation: Adhesive tape rear side
Stripe connection: 2 cables [V-, V+]
840190 2700 K [+/- 150 K] 720 LEDs 55 W 3700 lm / Stripe 1233 lm / Meter EEI: A
312321 3000 K [+/- 150 K] 720 LEDs 55 W 4000 lm / Stripe 1333 lm / Meter EEI: A
840191 4000 K [+/- 150 K] 720 LEDs 55 W 4000 lm / Stripe 1333 lm / Meter EEI: A
312322 6500 K [+/- 150 K] 720 LEDs 55 W 4000 lm / Stripe 1333 lm / Meter EEI: A
24 SMD - 15°C M M
3528 120° Ra>90 1 CH IP20 + 50°C
Cutting option
over to 25 mm / 6 LED
FLEXIBLE LED-STRIPE
Dim. L x W x H: 5000 x 10 x 3 mm
LED rows: 1
Fixation: Adhesive tape rear side
Stripe connection: 2 cables [V-, V+]
840192 2700 K [+/- 150 K] 1200 LEDs 90 W 5700 lm / Stripe 1140 lm / Meter EEI: A
840193 3000 K [+/- 150 K] 1200 LEDs 90 W 6200 lm / Stripe 1240 lm / Meter EEI: A
840194 4000 K [+/- 150 K] 1200 LEDs 90 W 6300 lm / Stripe 1260 lm / Meter EEI: A
840195 6000 K [+/- 150 K] 1200 LEDs 90 W 6400 lm / Stripe 1280 lm / Meter EEI: A
24 SMD 120° Ra>90 1 CH IP20 - 15°C M M
3528 + 50°C
Cutting option
over to 25 mm / 6 LED
LED-STRIPES | 1 Channel 633
