Page 637 - Deko-Light Light Impressions 2019-20
P. 637
FLEXIBLE LED-STRIPE
RED | BLUE | GREEN | AMBER | VIOLET
Dim. L x W x H: 5000 x 8 x 3 mm
LED rows: 1
Fixation: Adhesive tape rear side
Stripe connection: 2 cables [V-, V+]
840231 R rot 620 nm 600 LEDs 35 W 300 lm / Stripe 60 lm / Meter EEI: A
840232 B blau 468 nm 600 LEDs 30 W 350 lm / Stripe 70 lm / Meter EEI: A
840233 G grün 520 nm 600 LEDs 36 W 1600 lm / Stripe 320 lm / Meter EEI: A
840234 A amber 590 nm 600 LEDs 36 W 180 lm / Stripe 36 lm / Meter EEI: A
840235 V violet 360 nm 600 LEDs 34 W 800 lm / Stripe 160 lm / Meter EEI: A
12 SMD 120° 1 CH IP20 - 15°C
3528 + 50°C
Cutting option
over to 25 mm / 3 LED
636 LED-STRIPES | 1 Channel
