134                       Applied Process Design for Chemical  and Petrochemical  Plants

                                                        1.  0
                                                         8
                                                         6
                                                         -
                                                         4
                                                                                                 .,'."'rimary condenser·'-
                                                         3
                                                                                                      Vent condenser
                                                         2-                   ._  t,.,...        -......  K.  ...._
                                                             -Section
                                                                ,Seftij>'].   --      '"'  �p,,   r-p,,   �k   ...   ��""�
             Figure  2-47.  Acceptable  pressure  losses                        """" """ ""-   """'   ...._
             between  the  vacuum  vessel  and  the  vacuum   .1   Sections  enc  4
             pump.  Note:  reference  sections  on  figure  to   8                                 �            ..
             system  diagram to  illustrate the sectional  type   6                         ,-p,,      ....
                                                         5
             hook-ups for connecting  lines.  Use 60%  of the   4
             pressure  loss  read  as  acceptable  loss  for the
             system from  process to vacuum pump,  for ini-   3
             tial estimate.  P  =  pressure drop (torr)  of line in   2
             question;  P 0  =  operating  pressure  of vacuum
             process  equipment,  absolute, torr.  By  permis-
             sion,  Ryans,  J.  L.  and  Roper,  D.  L.,  Process   0.0  1
             Vacuum System Design & Operation,  McGraw-   1     2   3  4  6  6 7 8  10   2   3  4  6  6 78 100   2   3  4  6  6 7 8  1000
             Hill Book Co., Inc., 1986 [18].                                 Pressure in vacuum ve.l P0


              Fanning  or  Moody  friction  charts  and  are  beyond  the   used  as  the viscosity  factor in  the  pressure  drop  calcula-
              scope  of this  chapter.  Design  literature  is  very  limited,   tions.  The two principal  classifications are  [25]:
              with  some of the current available  references  being  Sul-
              tan  [21], Bird et  al.  [22], Cheremisinoff,  N. P.  and Gupta   1. Newtonian  slurries  are  simple  rheological  property
              [14], Perry et al.  [5], and Brodkey and Hershey  [23].   viscosities,  and can  be  treated as  true fluids as  long
                                                                        as  the  flowing  velocity  is  sufficient  to  prevent  the
              Slurry Flow in Process Plant Piping                       dropout of  solids.  For this  type of  slurry,  the viscosi-
                                                                        ty= µ.
                Most industrial  process plants have from none to a few   2.  Bingham-plastic  slurries  require  a  shear  stress  dia-
              slurry  flow  lines  to  transport  process  fluids.  The  more   gram showing shear rate vs.  shear stress for the slurry
              common  slurry lines discussed in the literature deal with   in  order  to  determine  the  coefficient of rigidity,  T],
              long  transmission  lines  for  coal/water,  mine  tailings/   which is  the slope of the  plot at a particular concen-
              water,  limestone/water,  wood  pulp-fibers/water,  gravel/   tration. This is laboratory data requiring a rheometer,
              water,  and others.  These lines  usually can be expected  Lo   These are usually fine solids at high concentrations.
              have flow characteristics somewhat different than in-plant
              process slurries.  Considerable study has been made of the   Reference  [25]  has two practical  in-plant design  exam-
              subject, with the result that the complexity of  the variables   ples worked out.
              make  correlation  of  all  data  difficult,  especially  when   The pressure drop design method of Turian and Yuan
              dealing with short transfer lines.  For this reason, no single   [24]  is  the  development of the  analysis  of a  major litera-
              design  method is summarized here,  but rather reference   ture  data  review.  The  method  categorizes  slurry  flow
              is given to  the methods that appear most promising  (also   regimes  similar  in  concept  to  the  conventional  multi-
              see Reference  [30]).                                regime diagram for two-phase flow,  Figure 2-50. Their fric-
                Derammelaere  and  Wasp  [25]  present a  design  tech-   tion factor correlations are specific  to  the calculated flow
              nique  that ties  into  their classification  of slurries  as  het-   regime. See Figure 2-51  for one of  four typical plots in the
              erogeneous  and  homogeneous  (Figures  2-48  and  2-49).   original  reference.
              This method uses the Fanning friction factor and conven-   Example  calculations  are  included,  and  Figure  2-52
              tional  equations  for  pressure  drop.  The  recommended   illustrates  the effect of pipe size on  the  placement of the
              design slurry velocities range from 4 to 7 fl/sec.  Pipe abra-   flow regime.
              sion can be a problem for some  types  of solids when  the
              velocity approaches 10 ft/sec. For velocities below 4 ft/sec   Pressure Drop for Flashing Llquicls
              there  can  be  a  tendency  for  solids  to  settle  and  create
              blockage and  plugging of the line.                     Steam  is  the  most  common  liquid  that  is  flashed  in
                The  concentration  of the  solids  in  the  slurry  deter-   process  plants,  but of course,  it is  not the  only  one  as
              mines  the  slurry  rheology  or  viscosity.  This  property  is   many  processes  utilize  flash  operations  of  pure  com-
