SECTION N - METRIC TUBE FITTINGS &
ADAPTORS VISUAL INDEX

METRIC TUBE NUT METRIC TUBE CUTTING BSPT X METRIC (L) ADAPTOR BSPT X METRIC (S) ADAPTOR
(S-M...) N3 RINGS (S-R...) (NC...) N4 (SA2265...) N5 (SA2268...) N5

BSPT X METRIC Port ADAPTOR BSPP SS Dowty Seal BSPP X METRIC Tube Coupling BSPT X METRIC Tube Coupling
(SA1061...) N6 (S-DSM...) N6 (S-GEV...R-WD) N7 & N8 (S-GEV...RK) N9

METRIC Port X METRIC Tube BSPPF X METRIC Tube UN‘O’ X METRIC Tube NPT X METRIC Tube
(S-GEV...M-WD) N10 (S-GAV...R) N11 (S-GEV...UN) N12 (S-GEV...NPT) N13

NPT X METRIC Tube Elbow BSPT X METRIC Tube Elbow BSPP X METRIC Tube Elbow
(S-WEV...NPT) N14 (S-GEV...RK) N15 & 16 (S-WEV...R-AE) N16

METRIC Tube Straight Coupling METRIC Tube Reducing Coupling METRIC Tube Elbow METRIC Tube Tee
(S-GV...) N17 (S-GV.../...) N18 (S-WV...) N19 (S-TV...) N20
