ORFS X TUBEWELD ORFS X METRIC TUBEWELD

A B A B

Part No Thread A Connection B Part No Thread A Connection B
(ORFS) (OD TUBE) (ORFS) (OD TUBE)
A88960904 9/16” 1/4” A88990906 9/16” 6MM
A88960906 9/16” 3/8” A88990908 9/16” 8MM
A88960908 9/16” 1/2” A88990910 9/16” 10MM
A88961106 11/16” 3/8” A88991110 11/16” 10MM
A88961108 11/16” 1/2” A88991112 11/16” 12MM
A88961110 11/16” 5/8” A88991115 11/16” 15MM
A88961306 13/16” 3/8” A88991312 13/16” 12MM
A88961308 13/16” 1/2” A88991315 13/16” 15MM
A88961308SCH 13/16” 21.3MM A88991316 13/16” 16MM
A88961310 13/16” 5/8” A88991318 13/16” 18MM
A88961312 13/16” 3/4” A88991320 13/16” 20MM
A88961610 1” 5/8” A88991616 1” 16MM
A88961612 1” 3/4” A88991618 1” 18MM
A88961912 1.3/16” 3/4” A88991620 1” 20MM
A88961916 1.3/16” 1” A88991918 1.3/16” 18MM
A88962316 1.7/16” 1” A88991922 1.3/16” 22MM
A88962320 1.7/16” 1.1/4” A88991925 1.3/16” 25MM
A88962716 1.11/16” 1” A88992325 1.7/16” 25MM
A88962720 1.11/16” 1.1/4” A88992328 1.7/16” 28MM
A88962724 1.11/16” 1.1/2” A88992330 1.7/16” 30MM
A88963224 2” 1.1/2” A88992332 1.7/16” 32MM
A88992732 1.11/16” 32MM
A88992735 1.11/16” 35MM
A88992738 1.11/16” 38MM
A88993235 2” 35MM
A88993238 2” 38MM
