Page 60 - Fluid Fitting 2018_extended

BSPP X TUBEWELD BSPP FEMALE SWIVEL X TUBEWELD

A B A B

Part No Thread A Connection B
Part No Thread A Connection B
(BSPP) (OD TUBE)
(BSPPFS) (OD TUBE)
A10960404 1/4” 1/4”
A17960404 1/4” 1/4”
A10960406 1/4” 3/8”
A17960606 3/8” 3/8”
A10960606 3/8” 3/8”
A17960608 3/8” 1/2”
A10960608 3/8” 1/2”
A17960808 1/2” 1/2”
A10960808 1/2” 1/2”
A17960810 1/2” 5/8”
A10960810 1/2” 5/8”
A17960812 1/2” 3/4”
A10960812 1/2” 3/4”
A17961212 3/4” 3/4”
A10961212 3/4” 3/4”
A17961216 3/4” 1”
A10961216 3/4” 1”
A17961616 1” 1”
A10961616 1” 1”
A17962020 1.1/4” 1.1/4”
A10961620 1” 1.1/4”
A17962424 1.1/2” 1.1/2”
A10962020 1.1/4” 1.1/4”
A17963232 2” 2”
A10962024 1.1/4” 1.1/2”
A10962424 1.1/2” 1.1/2”
A10963232 2” 2”

BSPP X SCHEDULE PIPE WELD BSPP FEMALE SWIVEL X SCHEDULE

PIPE WELD

A B
A B

Part No Thread A Connection B
(BSPP) (SCH PIPE Part No Thread A Connection B
OD)
(BSPPFS) (SCH PIPE OD)
A10960808SCH 1/2” 21.3MM
A17961212SCH 3/4” 26.7MM
A10961212SCH 3/4” 26.7MM
A17961216SCH 3/4” 33.4MM
A10961216SCH 3/4” 33.4MM
A17961616SCH 1” 33.4MM
A10961616SCH 1” 33.4MM
A17962020SCH 1.1/4” 42.2MM
A10961620SCH 1” 42.2MM
A17962424SCH 1.1/2” 48.3MM
A10962020SCH 1.1/4” 42.2MM
A10962424SCH 1.1/2” 48.3MM
