Push Clamps/Cylinders

Threaded-Body Push Clamps
Mini
page 652 Achieve high force in a compact size. Wide
variety of types and sizes. Various models
offer different mounting options, such as
using accessory brackets, screwing directly
into fixture, or manifold mounting.

Accessories, page 655

Single Acting
page 653

Block Clamps
Block Clamps are easy to mount
horizontally or vertically on flat surfaces.

Available single and double acting, are
excellent for punching and assembly
Block Clamps operations, with high forces available.
Wide range of sizes. Large sizes are often
pages 656-657
used for presswork applications (up to 180
tons).

Threaded-Body
Universal Cylinder
Achieve space-saving mounting in fixture
walls with this universal cylinder, in a wide
Threaded-Body range of sizes. Alternatively single acting
Universal Cylinder with spring return or double acting.
pages 658-659
