SECTION 6.0 – INTERIOR WORKS FURNISHING AND OTHER FITTINGS SECTION 6.0 – INTERIOR WORKS FURNISHING AND OTHER FITTINGS

a) Cafeteria shall be displayed outside of both doors, including the one leading to
b) Lift the Radiology Room.
c) Staircase
d) Public Phone e) In the Specialist Clinics, all C/E rooms and related rooms (as stated by
e) Male/Female Toilet the Client) shall be identified with a continuous numbering system. All
f) Disable Toilet other supporting rooms accessible to the public shall be identified with
g) Wash & Dry the same continuous numbering system, including individual rooms’
h) Changing Room name.
i) Prayer Room
j) Cleaner’s Room f) Numbering of the floors shall start with digit 1 (inclusive of the
k) Breast-Feeding / Nursing / Feeding Room subterranean floor).
l) Nappy Change / Baby Changing / Parenting Room
m) Shower g) In the Operation Theatre Department, all OT rooms shall have a
n) Radiation/Radioactive continuous numbering system. All doors opening into the OT rooms
o) Silence shall display the same number of the OT rooms. The same number shall
p) No Handphones also be displayed at the end of the OT’s exit corridor. All other
q) No Smoking supporting rooms shall be identified with the same number of the OT,
and it is attached to, together with its room name, e.g., Scrub 2 for scrub
6.6.18 Numbering systems and zoning shall be provided for parking lots. room to OT number 2.

6.6.19 Residential units shall be provided with external directional signs, block h) All rooms accessible to the public, patient cubicles, and bays in the
numbers, unit door numbers, architectural codes, M&E signage (including Accident and Emergency Department.
JBPM’s requirements), and letterbox numbers (if required).

6.6.20 Visual scale shall apply to the signage based on distances, colours used, i) Counters such as pharmacy, admission and revenue, registration, and
and font types. Consideration shall be given to legibility and contrast to aid others as identified by the Client.
the visually impaired visitors.
6.6.23 The Client’s Charter with an appropriate design and sizes as agreed by the
6.6.21 Mock-ups of various types of signage shall be submitted for the PD’s Client shall be provided for various departments as follows:
approval before full installation of the said project.
Mission Client’s Workflow
6.6.22 Numbering Systems shall be provided for various functions as listed below: Department and Vision Charter Chart
Board
a) All patient beds include patient couches where beds with the patients’ Administration / / /
name-slots shall also be displayed outside the room. Specialist Clinics / /
Central Registration / /
/
/
Continuing Medical Education
b) All multiple rooms, e.g., Treatment Rooms, Procedure Rooms, C/E (CME)
Rooms, and X-ray rooms. Main Lobby / / /
Admission/Revenue / /
c) All wards shall be identified by floor/level and zone, using numbers and Outpatient Pharmacy / /
alphabets. This identification and its specific name shall appear in the Specialist Office / /
main hospital directory signage in the main lobby, e.g., Wad 3A (Wad Wards / /
Pediatrik). Imaging and Diagnostic / /
All other departments where / /
d) All Radiology Rooms and any other clinical rooms with changing required by the Client except
cubicles for patients shall have the same continuous numbering catering and privatised service
system. The attached changing cubicles’ signages shall be based on
the same number of the Radiology Rooms and alphabets (e.g., 3A and
3B for Radiology Room number 3). The signs for these changing rooms
86 87
