END MILLS

3000 Intimidator - Radius End

Tool Cutting Shank Overall Corner Weldon EDP Number
Cutting Diameter Length Length Diameter Length Radius Flat
Style FC 18
XL 2 1/2 4 .1200 ü 34502
XL 3 1/2 5 .0300 34248
XL 3 1/2 5 .0300 ü 34534
XL 3 1/2 5 .0600 34249
1/2 XL 3 1/2 5 .0600 ü 34535
XL 3 1/2 5 .0900 34250
XL 3 1/2 5 .0900 ü 34536
XL 3 1/2 5 .1200 34251
XL 3 1/2 5 .1200 ü 34537
SD 1 1/4 5/8 3 1/2 .0300 ü 34421
SD 1 1/4 5/8 3 1/2 .0600 ü 34423
XL 2 1/4 5/8 5 .0300 34266
XL 2 1/4 5/8 5 .0300 ü 34538
XL 2 1/4 5/8 5 .0600 34267
5/8
XL 2 1/4 5/8 5 .0600 ü 34539
XL 2 1/4 5/8 5 .0900 34268
XL 2 1/4 5/8 5 .0900 ü 34540
XL 2 1/4 5/8 5 .1200 34269
XL 2 1/4 5/8 5 .1200 ü 34541
SD 1 1/2 3/4 4 .0300 ü 34426
SD 1 1/2 3/4 4 .0450 ü 34427
XL 3 3/4 6 .0300 34331
XL 3 3/4 6 .0300 ü 34542
XL 3 3/4 6 .0600 34332
3/4
XL 3 3/4 6 .0600 ü 34543
XL 3 3/4 6 .0900 34333
XL 3 3/4 6 .0900 ü 34544
XL 3 3/4 6 .1200 34334
XL 3 3/4 6 .1200 ü 34545
XL 3 1 6 .0300 34363
XL 3 1 6 .0300 ü 34546
XL 3 1 6 .0600 34368
XL 3 1 6 .0600 ü 34547
1
XL 3 1 6 .0900 34365
XL 3 1 6 .0900 ü 34548
XL 3 1 6 .1200 34367
XL 3 1 6 .1200 ü 34549
Metric
4.00 SD 14.00 4.00 50.00 0.50 93811
SD 22.00 8.00 64.00 0.50 93817
8.00
SD 22.00 8.00 64.00 1.00 93819

I M

IMPERIAL METRIC

■ Titanium ■ Super Alloys ■ Hardened Steels ■ Stainless Steels ■ Steels ■ Cast Iron ■ General Purpose
